REA JET –HR - Innovative, Maintenance-Free Product
Marking: High Resolution Ink Jet Printers (HP)
The high resolution ink jet printers with HP print technology utilize the thermal ink jet technology that is trusted by millions of users. The robust stainless steel housing, the intuitive operation and well-conceived print head design make this coding and marking system suitable for unlimited industrial-strength applications. The system particularly proves its worth in the pharmaceutical, food, wood, paper and packaging industries. For marking at a print height of 12.7 mm per cartridge. If greater print heights are required, several print heads can be cascaded. With its integrated Ethernet interface and full Unicode support (UTF 8), the HR print system is the system of choice for serialization tasks and track & trace projects. Up to 4 print heads are supported, depending on type of equipment

Advantages :-

  • Utilizes the HP thermal ink jet technology (TIJ) that is trusted by millions of users of office printers maintenance-free – every time you change a cartridge, you receive a new print head n permanent storage of the various cartridge fill levels n monitoring of cartridge locking .
  • Highest operational reliability.
  • Easy and intuitive operation due to central push-turn jog-dial knob.
  • International, due to Unicode character set (UTF 8) and multi-voltage power supply.
  • XML-based data structure and communication.
  • Lowest (ink) consumption due to precisely scalable font size and rasterization.
  • State of the art interface technology, for integration into machinery and equipment.
  • Easy cascadability of print heads: Due to precise, permanently installed mounting aids the print heads can be easily and accurately cascaded n controller in stainless steel housing with IP65 protection class.
  • Optional accessories such as robust, easy-toconfi gure parallelogram for distance offset in different product positions during printing.
  REA JET HR 2K REA JET HR 4K REA JET HR pro 2K REA JET HR pro 4K
Dimensions (approx.) (L / W / H)Weight 308 x 287 x 142 mm10 kg 355 x 287 x 142 mm9,1 kg 265 x 176 x 100 mm4,1 kg 350 x 176 x 100 mm8 kg
Protection class of the housing IP 65 IP 65 IP 20 IP 20
Max. attachable print heads 2 4 2 4
Max. marking height 25,4 mm 50,8 mm 25,4 mm 50,8 mm
Digital inputs (24V DC) 6 12 6 12
Processing performance Standard Standard High performance Especially suitable for serialization applications
Device display - Type - Size Full-colour graphic display Diagonal from approx. 14.4 cm (5.7 inch) Full-colour graphic display Diagonal from approx. 8.9 cm (3.5 inch)
Operating element Numeric keypad and cursor keys, the keys Start, Stop, ESC, DEL, OK, HELP, Menu und Backspace, fi ve context dependent functional keys and a rotary knob with push-button function The network address can be set and a job can be selected and assigned on the device.
Device operation Especially suitable for Especially suitable for OEM /
Applications where the entries will be made on-site. Machine integration.
Webserver Yes Yes Yes Yes
VNC Yes Yes Yes Yes
