Thermal Transfer Over Printer
UCS1 intermitted digital thermal transfer printer and UCS2 continuous digital thermal transfer printer provides an economic solutions to end user who are looking at upgrading from hot stamp or hot ink roll coders to a reliable and dependable digital printer.

Reliable and dependable on-line print performance
With a large installed base of over a thousand printers and time tested, UCS printers have proven its reliability and dependability to our many satisfied end users. At the same time it also helps them in reducing the service and maintenance time significantly.

Easy to learn and to operate :-

  • Easy on-line file creation using the keypad and LED display screen. No PC is needed.
  • LED display of actual job file ensures correct information being printed thus avoiding error in printing.

Economic values :-

  • Investment cost is relatively more economical comparing to other thermal transfer printers in the market. It’s well within the budget for those customers who are ready for digital thermal transfer printing.
  • 450 meter ribbon length reduces ribbon change frequency, increase production uptime.
  • Optimized usage of ribbon reduces consumable cost.
  • Cheaper parts cost translating to lower operating cost.
Machine Model UCS1 (Intermittent) UCS2 (Continuous)
Print Speed 225mm/s 500PPM 50-650mm/s
Ribbon Size 32mm x 450M Outside Ink
Ribbon Gap 0.5mm and User Adjustable
Software Interface RS232 Industrial Port
Hardware Interface Input: Print Trigger
Output: Print, Warning, Fault		 Input : Print Trigger, Encoder
Output : Print, Warning, Fault
User Interface Job create without PC
Self-Diagnostic
Warning and Fault information
3.5 Inch blue backlight LED
Durable, robust metal casing
Weigh: Approx 3.8 KG
Print Body Image Rotation, Font Selection
Support Logo, Chinese Print
Serialize, customized printing
Real time, date, expiry date
Weight: Approx 6.0 KG
Power/ Air Supply 100~120AC or 220~240vac /Max 6.0 Bar Compressed Air
Operating Environment Temperature 0~40 degree C / Humidity: 0~9%s
